Features:

  • Full inverter technology

    The unit is equipped with a full Inverter compressor and fan motor. In addition with falling film technology, the uni will achieve the much better efficient and much lower power consumption.

  • Wide application range.

     1, Wide cooling capacity range from 5 to 30 tons.
     2, Cooling only type from 10°C to 52°C ambient in cooling mode.
     3, Heat pump type from 10°C to 46°C / -9°C to 24°C ambient in cooling mode / heating mode.
     4, Vertical side-discharge structure design.
     5, Flanges of air flow inlet and outlet as standard.
     6, It is suitable for installation on rooftop and ground.

  • Easy installation.

     1, Removable access door on the electric box. It is easy to move the cover of the electric box.
     2, Only connect the wires of power supply, and no need to connect any signal wires.
     3, Reserved external drainage port, quickly and accurately connect the rubber drainage pipe.

  • Easy maintenance.

     1, The unit provides external pressure gauge ports for convenient and fast checking system pressure without removing the panel.
     2, Removable access doors on the filter, fan motor, and electric box sections.
     3, Provide convenient access to system components for mainenance and service.

  • Outstanding reliability.

     1, Pre-painted exterior cabinet panels pass 500 hours Salt Spray Test for durability.
     2, Weather-resistant construction with capped steams and sloped top panels.
     3, G90 galvanized heavy gauge plate conforming to ASTM-A-653.
     4, The rooftop package air conditioners with special anti-corrosion treatment are suitable for seaside areas or the other areas
     5, Top brands compressor for option:Copeland, Hitachi, Danfoss, Invotech, etc
     6, No complex internal suction and discharge valves for quieter operation and higher reliability.
     7, Compact, light-weight, and fewer moving parts design.
     8, Multiply protection (system current protection, high/low pressure protection, temperature sensor protection, over/no load protection, etc. ) to ensure units operate normally and reliably.
     9, In the multi-system unit, the compressors can be started one by one according to the time and the load, and according to the cumulative running time of the compressor, it gives priority to start the compressor which has the shortest running time, so as to ensure the balance of each compressor's running time and to extend the service life of the whole unit.

  • Flexible choice of accessories.

     1, Optional standard wired controller.
     2, Besides standard wired controller, others can be chosen too.
     3, Other brand thermostat can be matched as optional solution.
     4, The unit can choose different levels of filters, primary filters G1-G4, GN, GH, GC, GT, medium efficiency filters F5-F9, high efficiency filters H12-H14, U15-U17, etc.
